4000:5 10KV Rectangular Housing Split Core 270R-402 270R402 | (1 Per Purchase)

270R-402 Split Core Current Transformer Current Ratio 4000:5; Voltage Rating 600 Volt; Accuracy 1.2 (B.1/B0.2/B0.5/B0.9/B1.8); BIL Rating 10 Kilovolt; Base Type Mounting Bracket; Burden B0.1/B0.2/B0.5/B0.9/B1.8; Rating Factor 0.75 at 55 Deg C; Wire Size 10 to 32 AWG; Window Size 3.56 Inch Width x 8.81 Inch Height; Housing Shape Rectangular; Application Load Surveying, Ground Fault Relaying, Metering; RoHS Compliant; DC Resistance 0.89 Ohm at 25 Deg C; Enclosure Type NEMA 1; Terminal Type Screw Clamp; Overall Dimension 13.06 Length x 9.25 Inch Width x 3 Inch Depth; Frequency Rating 60 Hertz; Includes Brass Screw, Flat Washer, Bronze Lock Washer - Used - 1 Per Purchase - 4000:5 Call or message us if you have any questions on this item!
